Read moreNew - PlaybackPro Plus X version 4.0.5 is now available.

Independently or simultaneously control up to 4 systems with the new DT18. Professional-grade backlit buttons provide easy access to essential show controls and playback functions.

UC12 UC40 DT18
Works With PlaybackPro
all versions
PlaybackPro Plus
all versions
all versions
PlaybackPro Plus (recommended)
all versions
PlaybackPro Plus
PlaybackPro Plus X
Number Systems 1 1 1 to 4
Connection USB USB Ethernet
Commands Keystrokes1 Keystrokes1 Direct to App1
Number Of Buttons 12 40 18
Number Of Functions 12 40 27
Buttons Un-lit Un-lit Professional Grade Backlit Buttons
Height 1.65" (4.19cm) 1.63" (4.14cm) 2.12" (5.39cm)
Width 3.79" (9.63cm) 8.25" (20.95cm) 6.42" (16.31cm)
Depth 5.80" (14.73cm) 7.25" (18.41cm) 7.07" (17.96cm)
Weight 9.6oz (.27kg) 24.8oz (.70kg) 29oz (.82kg)
Power USB USB External
110-240V~0.8A, 50-60Hz
12v DC, 2.5A
Firmware Update Not Available Not Available From App
Latest Firmware Version Not Available Not Available 1.0
Made In Taiwan Taiwan USA
Price $249 $425 $799

1 - Keystroke commands are received by the application currently selected in the OS (in “focus”).
Direct to App commands are sent directly to a specific application regardless of window selection in the OS.

UC12 UC40 DT18
Show Controls
Delay icon
Loop Temp icon icon icon
Loop - icon icon
Loop + icon icon
Link Temp icon icon
Link - icon icon
Link + icon icon
Freeze Temp icon icon
Move To Top Of Playlist icon
Move To Bottom Of Playlist icon
Activate/Deactivate Ethernet Channels icon
Multiple Or Individual PlaybackPro Plus Control icon
Playback Functions
Play/Pause icon icon icon
Take icon icon icon
Next icon icon icon
Previous icon icon icon
Clear icon icon icon
Goto 10 icon icon icon
Goto 20 icon icon icon
Goto 30 icon icon icon
End All icon icon icon
End - icon icon
End + icon icon
Take Fade - icon icon
Take Fade + icon icon
Take - icon icon
Take + icon icon
Clip and Show Preparation
Save icon icon
Fast Reverse icon
Fast Forward icon
Step Back 1 Frame icon
Step Forward 1 Frame icon
Set In icon
Set Out icon
Goto In icon
Got Out icon
Play/Pause icon


Overview Video (02:58)


Computers (00:18)

Networking (00:44)

PlaybackPro Plus X (01:02)


Understanding Button Flashes on Startup (01:08)

Command Buttons (02:15)

Command Button Combinations (01:40)

Reset to Factory IP address (0:49)

Customize IP Address (02:18)


Fade on Take (00:37)

Link Temp (00:34)

Loop Temp (00:59)
